Building a CI/CD Pipeline with AWS, K8S, Docker, Ansible, Git, Github, Apache Maven, and Jenkinsby@zufarexplained
36,095 reads
36,095 reads

Building a CI/CD Pipeline with AWS, K8S, Docker, Ansible, Git, Github, Apache Maven, and Jenkins

by Zufar SunagatovSeptember 7th, 2023
Read on Terminal Reader
Read this story w/o Javascript

Too Long; Didn't Read

Learn how to create an advanced CI/CD pipeline with AWS, K8S, Docker, Ansible, Apache Maven, Git, Github, and Jenkins with Zufar Sunagatov. By the end of this tutorial, you will get a ready to use modern CI/CD pipeline which is applicable to any of your projects on Github.
featured image - Building a CI/CD Pipeline with AWS, K8S, Docker, Ansible, Git, Github, Apache Maven, and Jenkins
Zufar Sunagatov HackerNoon profile picture




In my previous article, I delved into the fascinating world of microservices - Microservice Architecture Patterns Part 1: Decomposition Patterns. This was the beginning of my comprehensive article series on microservices and their patterns.


While the logical step would be to continue with Part 2 of this series, I have decided that the next thing that I would like to explore and tell you about is the vital process of delivering these microservices to the end user seamlessly.


Content Overview

  • Motivation
  • [Module 1]: AWS EC2 Virtual Server
  • [Module 2]: Jenkins Server
  • [Module 3]: Git and Github
  • [Module 4]: Apache Maven
  • [Module 5]: Docker
  • [Module 6]: Ansible
  • [Module 7]: Kubernetes
  • Conclusion
  • About the Author



Motivation

CI/CD is a technique for delivering apps to customers, achieved by adding automation to different stages of app development. I believe that grasping CI/CD (Continuous Integration and Continuous Deployment) can empower developers to gain a better understanding of how backend project artifacts exist beyond the boundaries of the project repository. This comprehension can also create a fundamental shift in a developer's perspective. Instead of merely viewing their work as lines of code, they can start to embrace the broader context of their project as a valuable product.


In this article, we aim to demystify the CI/CD process through practical application. We'll take you through a step-by-step tutorial, breaking it down module by module, where you'll build a CI/CD pipeline manually. To do this, we'll harness the power of contemporary DevOps tools like AWS, Docker, Kubernetes, Ansible, Git, Apache Maven, and Jenkins. So, let's begin this journey!


[Module 1]: AWS EC2 Virtual Server

This module is dedicated to the creation of an AWS EC2 Virtual Server instance. As part of this article, you will be setting up three EC2 instances for Jenkins, Ansible, and Kubernetes. For now, you can proceed with the next modules and revisit this module in "[module 2]: Jenkins", “[module 6]: Ansible" and "[module 7]: Kubernetes" sections.


Step 1: Create an AWS Account

Go to https://aws.amazon.com.

Click the button Create an AWS Account.


The screenshot of AWS main web page with the pointer to "Create an AWS Account" button


Follow the instructions on the create account web page.


Step 2: Sign In to your AWS Account

Go to https://console.aws.amazon.com/console/home. Click the Sign In button.

The screenshot of AWS main web page with the pointer to "Sign In" button


Enter all necessary credentials on this web page.


Step 3: Find EC2 Virtual Server

Find EC2 in the search box.

The screenshot of AWS web page with the pointer to the search box


Choose EC2 Virtual Server by clicking EC2 Service.

The screenshot of AWS web page with the pointer to "EC2" AWS service


Click the button Launch Instance.

The screenshot of AWS web page with the pointer to "Launch instance" button


Step 4: Configure “Name and tags“ section

Go to the “Name and tags” section.

The screenshot of AWS web page with the pointer to "Name and tags" section


Provide a name for a new AWS EC2 Virtual Server instance in the “Name” section.

The screenshot of AWS web page with the pointer to "Name" input box in "Name and tags" section


You can also add additional tags for your virtual server by clicking ”Add additional tags”.


Step 5: Configure “Application and OS Images (Amazon Machine Image)“ section


Go to the "Application and OS Images (Amazon Machine Image)" section.

The screenshot of AWS web page with the pointer to "Application and OS Images (Amazon Machine Image)" section


To play with the virtual server for FREE:

  1. Select the operating system for your virtual server - Amazon Linux.
  2. In the Amazon Machine Image (AMI) section, select a machine with the Free tier eligible tag.



The screenshot of AWS web page with the pointer to "OS" and "Machine type" buttons in "Application and OS Images (Amazon Machine Image)" section


Step 6: Configure “Instance type“ section

Go to the ”Instance type” section.

The screenshot of AWS web page with the pointer to "Instance type" section


To play with the virtual server for FREE:

Select a type with the Free tier eligible tag in the Instance type section.

For me it is t2.micro (Family: t2 1cCPU 1 GiB Memory Current generation:true).



The screenshot of AWS web page with the pointer to "Instance type" dropdown in "Instance type" section


Step 7: Configure “Configure storage“ section

Go to the ”Configure storage” section.

The screenshot of AWS web page with the pointer to "Configure storage" section


To play with the virtual server for FREE:

Do not change default settings. Free tier eligible customers can get 30 GB of EBS General Purpose (SSD) or Magnetic storage.



The screenshot of AWS web page with the pointer to storage possible configurations in "Configure storage" section


Step 8: Configure “Network settings“ section

Go to the “Network settings“ section.

The screenshot of AWS web page with the pointer to "Network settings" section


You need to set up the security of your virtual server. To do this,

  1. Click on the “Create security group” button.
  2. Add the name of your new security group in the “Security group name” section.
  3. Add a description of your new security group in the “Description” section.

By default, your virtual server is accessible via (Type - SSH, Protocol - TCP, Port - 22). If you need additional connection types, add them by adding additional inbound security group rules.



The screenshot of AWS web page with the pointer to "Security group" in "Network settings" section


Step 9: Configure “Key pair (login)“ section

Go to the ”Key pair (Login)” section.

The screenshot of AWS web page with the pointer to "Ket pair (login)" section


Create a new key-pair if you haven't created it yet.

The screenshot of AWS web page with the pointer to "Key pair name", "Key pair type", "Private key file format" in "Ket pair (login)" section


If you haven't created “key-pair” yet:

  1. Click the “Create new key pair” button.
  2. Give your new key-pair a name in the “Key pair name” section.
  3. Select key-pair type RSA or ED25519. I choose the RSA type.
  4. Select Private key file format. Choice of .pem and .ppk. I choose the .pem format.
  5. Click on the “Create key pair” button.
  6. You will get a pop-up window that will prompt you to download the Private key file. Agree and download the file to your computer.

Step 10: Launch the EC2 Virtual Server Instance


Launch the EC2 Virtual Server instance by clicking the button “Launch instance”.

The screenshot of AWS web page with the pointer to "Launch Instance" button


After the completion of the EC2 Virtual Server instance creation process, you will see the following.


The screenshot of the AWS web page displaying a 'Success' notification, indicating the successful completion of the EC2 Virtual Server instance creation process


Then you should go to the “Instances“ section by clicking “View all instances” button.


The screenshot of AWS web page with the pointer to running EC2 instance

Now you can see that your AWS EC2 Virtual Server instance is running.



[Module 2]: Jenkins Server

Now, let’s configure JenkinsServer on the EC2 Virtual Server instance.

Step 1: Create an AWS EC2 Virtual Server instance

You need a virtual server to run Jenkins.

Follow instructions from [Module 1]: AWS EC2 Virtual Server section of this tutorial to finish this step and create an EC2 virtual server instance with the name JenkinsServer.

Do not forget to add a security group setup. It allows Jenkins and SSH to work on port 8080 and 22 respectively.


Use the name “JenkinsServer” to distinguish your EC2 Virtual Server instance.

Create “CI_CD_Pipeline” security group and “CI_CD_Pipeline_Key_Pair“ for a new “JenkinsServer” AWS EC2 instance. You can reuse them further in the article.


Step 2: Connect to an AWS EC2 Virtual Server instance

Go to AWS Console home page → EC2 Management Console Dashboard → Instances.

Then you should choose JenkinsServer and then click the “Connect” button.

The screenshot of AWS "Instances" web page with the pointer to "Connect" button


Then you will see this web page. You should again click the “Connect” button.

The screenshot of AWS "Connect to Instance" web page with the pointer to "Connect" button


Now you can see EC2 virtual server instance online terminal.

The screenshot of AWS EC2 Virtual Server instance online terminal


Step 3: Download the Jenkins repository

Now you need to download Jenkins on your EC2 virtual server instance.

Follow these instructions:


  1. Go to Jenkins download webpage.

  2. You can see Stable (LTS) and Regular releases (Weekly) options. Choose Red Hat/Fedora/Alma/Rocky/CentOSLTS option.


You will see this web page.

The screenshot of Jenkins download web page


  1. Copy “sudo get..” command and execute it to download Jenkins files from the Jenkins repository on the Internet and save them to the specified location on your EC2 virtual server instance.
sudo wget -O /etc/yum.repos.d/jenkins.repo https://pkg.jenkins.io/redhat-stable/jenkins.repo

Now Jenkins is downloaded.


Step 4: Import Jenkins key

To finish the Jenkins installation, we need to import the Jenkins key.

To import the Jenkins key we need to copy the “sudo rpm..” command and execute it.


sudo rpm --import https://pkg.jenkins.io/redhat-stable/jenkins.io-2023.key

This way “rpm” package manager can verify that the Jenkins packages you install are exactly the ones published by the Jenkins project, and that they haven't been tampered with or corrupted.


Step 5: Install Java

To run Jenkins, we need to install Java on our EC2 virtual server instance.

To install Java, use this command.


sudo amazon-linux-extras install java-openjdk11 -y


Verify whether Java was installed correctly using this command:

java -version


You will see something like that.

The screenshot of AWS EC2 Virtual Server instance online terminal with installed JDK 11


Step 6: Install fontconfig

To run Jenkins, you need to install fontconfig on our EC2 virtual server instance.

Use this command.

sudo yum install fontconfig java-11-openjdk -y


Fontconfig is a library designed to provide system-wide font configuration, customization and application access. It's required by Jenkins because Jenkins has features that render fonts.


Step 7: Install Jenkins

In earlier steps, you configured your EC2 virtual server instance to use a specific Jenkins repository and then you imported the GPG key associated with this repository. Now, you need to run the command that will search all the repositories it knows about, including the Jenkins one you added, to find the Jenkins package. Once it finds the Jenkins package in the Jenkins repository, it will download and install it.


Let’s run this command.

sudo yum install jenkins -y


Step 8: Start Jenkins

You can start Jenkins using this command.

sudo systemctl start jenkins


To check that Jenkins is running use this command.

sudo systemctl status jenkins


You will see the output as it is on the screenshot below:

The screenshot of AWS EC2 Virtual Server instance online terminal with installed Jenkins


Jenkins should now be up and running.

Step 9: Access Jenkins

To access the Jenkins application, open any web browser and enter your EC2 instance’s public IP address or domain name followed by port 8080.


http://<your-ec2-ip>:8080


The first time you access Jenkins, it will be locked with an autogenerated password.

The screenshot of Jenkins installed on AWS EC2 Virtual Server with the pointer to Administrator password


You need to display this password using the following command.

sudo cat /var/lib/jenkins/secrets/initialAdminPassword


Copy this password, return to your browser, paste it into the Administrator password field, and click "Continue".


Then you will be able to see this web page.


The screenshot of Jenkins installed on AWS EC2 Virtual Server with the pointer to "Customize Jenkins" web page


Now, you can use your Jenkins Server.


Step 10: Create new Jenkins pipeline

Now, as Jenkins is working fine, you can start creating the Jenkins pipeline. To create Jenkins pipeline you need to create a new “Freestyle project”. To create a new “Freestyle project” you need to go to the Jenkins dashboard and click the “New Item” button.


The screenshot of Jenkins Dashboard web page with the pointer to "New Item" button


Enter the name of the Github “Freestyle project” (“pipeline” name is going to be used further) and then click the button “OK”.


The screenshot of Jenkins New Item web page with the pointer to "Item name" item box


Then provide the Description of the pipeline.

The screenshot of Jenkins Job configuration web page with the pointer to "Description" input box


Then click the button “Apply” and “Save”. After that, it means you created the fundament of the pipeline which is going to be built in this tutorial.



[Module 3]: Git and Github

Now as Jenkins is running on AWS EC2 Virtual Server instance, you can configure Git with the pipeline.

Git is a free and open source distributed version control system (VCS) designed to help software teams keep track of every modification to the code in a special kind of database. If a mistake is made, developers can turn back the clock and compare earlier versions of the code to help fix the mistake while minimizing disruption to all team members. VCS is especially useful for DevOps teams since they help them to reduce development time and increase successful deployments [1].

Git as the most popular version control system enables us to pull the latest code from your project Github repository to your EC2 virtual server instance where your Jenkins is installed.


Step 1: Install Git

Use this command to install Git.

sudo yum install git -y


Now verify Git is working, using this command.

git --version

Now Git is working fine on EC2 Virtual Server instance.


Step 2: Open Jenkins dashboard

As Git is working fine on EC2 Virtual Server instance, we can integrate Jenkins with Git now.

To start this integration let’s install Jenkins Github plugin.

Go to Jenkins dashboard section.


The screenshot of Jenkins dashboard


Step 3: Open Jenkins Plugin Manager

Click the button “Manage Jenkins” and then click the button “Manage Plugins”.

The screenshot of Jenkins dashboard with the pointer to "Manage Plugins" button


Step 4: Find Github Jenkins plugin

Click the button “Available plugins”.

The screenshot of Jenkins Plugin Manager web page with the pointer to "Available plugins" button


Find the Github plugin Search box.


The screenshot of Jenkins Plugin Manager web page with the pointer to "Github" plugin


Select Github plugin.


Step 5: Install Github Jenkins plugin

Select Github plugin. And then click the button “Install without restart”.


The screenshot of Jenkins Plugin Manager web page with the pointer to "Install without restart" button


Wait for the end of the Github plugin downloading.


The screenshot of Jenkins Plugin Manager web page with the downloading Github plugin


Yes! The Jenkins Github plugin is installed.


Step 6: Configure Github Jenkins Plugin

Now as the GitHub Jenkins plugin is installed, you can configure this plugin to integrate Jenkins with Git finally. To do that you need to return to the main page by clicking the button “Go back to the top page”.


The screenshot of Jenkins Plugin Manager web page with the pointer to "Go back to the top page" button


Then on the main page, you need to click the button “Manage Jenkins” and then click the button “Global tool configuration”.


The screenshot of Jenkins Plugin Manager web page with the pointer to "Global tool configuration" button


Then on the Global Tool Configuration web page you should go to the Git section.


The screenshot of Jenkins Global Tool Configuration web page with the pointer to "Name" and "Path to Git executable" input boxes


In the Git section, you need to configure Git by providing the name and path to Git on the computer.


Then click the “Apply” and “Save” buttons**.**


Here, you have finished configuring the Jenkins Github plugin.


Step 7: Integrate Git into the pipeline

Now, as the Jenkins Github plugin is installed and configured, you're now able to utilize this plugin within your pipeline. This will allow your pipeline which you created in module 2 to pull your project code from the specified GitHub repository.


Well, to integrate this plugin into your pipeline you need to go to the Source Code Management section and choose Git in your pipeline. Then you need to provide your project repository URL. If your project repository is public on Github, you do not need to provide credentials. If the project repository is private on Github, you need to provide credentials.


The screenshot of Jenkins Job configuration web page with "Source Code Management" settings


You can use my project with the next Repositiry URL: https://github.com/Sunagatov/Hello.git.

Just copy and paste it to the “Repository URL” input. Then click the “Apply” and “Save” buttons to finish the integration Git with the pipeline.


Step 8: Test Git integrated into the pipeline

Now you can use your updated pipeline to pull a project from Github. To do that you need to click the **“Build Now”**button. As a result, you will see a successful build in the build history.


The screenshot of Jenkins web page with pointers to "Build Now" button and "Build History" section



Open the first build from the build history.

The screenshot of Jenkins Pull_Code_From_Github_Job with successful job result


Now you can see the successful job result of the first build. If you open your AWS EC2 terminal. You can check that the pipeline works well.


Just use this command.

cd /var/lib/jenkins/workspace/{your pipeline name}


This way you can see that your project from Github was pulled to your AWS EC2 virtual server instance.


The screenshot of Github project downloaded into EC2 instance terminal



[Module 4]: Apache Maven

Apache Maven is a widely used build automation and project management tool in software development. It streamlines the process of compiling, testing, and packaging code by managing project dependencies and providing a consistent build lifecycle. Maven employs XML-based configuration files (POM files) to define project structure, dependencies, and tasks, enabling developers to efficiently manage and deploy complex software projects.


Now that you have integrated Git into the pipeline, you can enhance the pipeline further by incorporating Apache Maven which enables you to build, test, and package your project. To do that you need to install Apache Maven on your AWS EC2 Virtual Server instance where Jenkins and Git were installed.


Step 1: Download Apache Maven

To download Apache Maven go to the “/opt” directory.

cd /opt


And then use this command.

sudo wget https://dlcdn.apache.org/maven/maven-3/3.9.4/binaries/apache-maven-3.9.4-bin.tar.gz


This command will download the latest official Apache Maven (check the latest version on the official Apache Maven website). To find the latest official Apache Maven release, use the link https://maven.apache.org/download.cgi.


Step 2: Extract Apache Maven from the archive

Use this command, to extract Apache Maven from the downloaded archive:

sudo tar -xvzf apache-maven-*.tar.gz


Step 3: Add JAVA_HOME and M2_HOME

Move to the root folder using this command.

cd ~


Edit .bash_profile file using this command.

vi .bash_profile


Add JAVA_HOME and M2_HOME variables.


Assign the path to JDK11 for JAVA_HOME and path to the maven directory for M2_HOME variable.


To find JDK path, use this command.

sudo find / -name java



The screenshot of AWS EC2 Virtual Server instance terminal web page with .bash_profile file


How to use VIM

  • To edit the file press the keyboard button “ I “ to insert data.
  • To save the file press the keyboard button “ esc “ and enter “:w“.
  • To exit from the file press the keyboard button “ esc “ and enter “:q”.

Save the changes.


Then, execute this command to refresh system variables.

source .bash_profile


To verify $PATH, use this command.

echo $PATH


To verify Apache Maven, use this command.

mvn -v


If you have done everything correctly, you will be able to view the version of Apache Maven.

The screenshot of AWS EC2 Virtual Server instance terminal web page with the version of Apache Maven


Step 4: Install Apache Maven Jenkins plugin

Since Apache Maven can be used on an EC2 instance, you can install the Apache Maven plugin to integrate it with the pipeline.


To achieve this, follow these steps:

  1. Navigate to “Dashboard“ → “Manage Jenkins“ → “Manage Plugins“ → “Available”.
  2. In the search box, enter “Maven”.
  3. Choose “Maven Integration” plugin.


The screenshot of Jenkins installed on AWS EC2 Virtual Server with the pointer to Maven plugin


Wait for the end of the downloading process.


And then click the button “Go back to the top page”.

The screenshot of Jenkins installed on AWS EC2 Virtual Server with the pointer to Maven plugin downloading process


Step 5: Configure Apache Maven Jenkins plugin

With the successful installation of the Apache Maven Jenkins plugin, you are now able to utilize this plugin within the pipeline which you created and updated in modules 2 and 3.


To do so, follow these steps:

  1. Go to “Dashboard“ → “Manage Jenkins“ → “Global Tool Coonfiguration“ → “JDK”
  2. Click the button “Add JDK”.
  3. Uncheck “Install automatically”.



The screenshot of Jenkins installed on AWS EC2 Virtual Server with the pointer to JDK configuration



Then go to “Maven” section. Click the button “Add Maven”. Uncheck “Install automatically”.

Then add name and MAVEN_HOME path.



The screenshot of Jenkins installed on AWS EC2 Virtual Server with the pointer to Apache Maven configuration



Click the “Apply” and “Save” buttons.

Here, you have finished configuring the Apache Maven Jenkins plugin.


Step 6: Integrate Apache Maven into the pipeline

Now as the Apache Maven GitHub plugin is installed and configured, you're now able to utilize Apache Maven within your pipeline. This will allow your pipeline which you created in the “[module 2]: Jenkins Server” to build your project code to create a jar artifact.


To integrate Apache Maven into the pipeline you need to follow these steps:

  1. Navigate to “Dashboard“ → “CI_CD_Pipeline“ → “Configure“ → “Build Steps”.
  2. Click “Add build step” button.
  3. Choose “Invoke top-level Maven targets” option.
  4. Choose “Apache-Maven” as “Maven Version”.
  5. Add “clean package” command to “Goals” input.
  6. Click “Advanced“ button.
  7. Add “pom.xml” to “POM” input.



The screenshot of "Build Steps" section in the pipeline configuration with pointers to "Apply" and "Save" buttons



Finally, you should click “Apply” and “Save” buttons to finish the integration of Apache Maven with the pipeline.

Step 7: Test Apache Maven integrated into the pipeline

Now you can use your updated pipeline to build your Github project. To do that you need to click the **“Build Now”**button. As a result, you will see a successful job result in the build history.

If you open your AWS EC2 terminal. You can check that the pipeline works well.


Just use this command.

cd /var/lib/jenkins/workspace/{your pipeline name}/target


This way you can see the JAR artifact, indicating the successful build of your project from GitHub.



[Module 5]: Docker

Now let’s create a new EC2 instance with the name "Ansible Server" where you are going to install Docker and Ansible.


Step 1: Launch an AWS EC2 Virtual Server instance

Use instructions from “Launch an AWS EC2 Virtual Server instance” section of this tutorial to finish this step. Do not forget to add a security group setup. It allows Docker and SSH to work on ports 8080 and 22 respectively.


Step 2: Connect to an AWS EC2 Virtual Server instance

Click the “Connect” button.

The screenshot of AWS web page with the pointer to "Connect" button


Now you can see the EC2 Virtual Server instance online terminal.

The screenshot of AWS EC2 Virtual Server instance online terminal


sudo chown ansible-admin:ansible-admin /opt/docker


Step 3: Install Docker on the Ansible EC2 virtual server.

Now you need to install docker on your Ansible EC2 instance. To do that you need to create a new docker folder.

sudo mkdir /opt/docker


Then, install docker by executing the next command.

sudo yum install docker -y


Step 4: Add current user to Docker group on Ansible EC2 virtual server

You need to add the current user “ansible-admin” to the Docker group on the “AnsibleServer” EC2 virtual server to give Docker admin privileges.


sudo usermod -a -G docker ansible-admin


You will need to logout and log back in for these changes to take effect.


Then you can execute the next command

id ansible-admin


to see that the new docker user exists.


The screenshot of Ansible EC2 instance with the pointer to the docker user


Step 5: Launch Docker

Now as Docker is installed on the Ansible EC2 instance you can launch it by executing the next command.

sudo systemctl start docker


As Docker is started you can execute the next command

sudo systemctl status docker


to see that docker is active and running now.

The screenshot of Ansible EC2 instance with the active docker status


Step 6: Create Dockerfile

In the final version of the pipeline, the process will involve creating a new Docker image from your GitHub project and pushing it to Docker Hub. To accomplish this, your GitHub project should contain a Dockerfile.


If you used the project “Hello” which was offered in “[Module 3]: Git and Github” module, then you don’t need to create a new Dockerfile as this project repository has already contained Dockerfile.


FROM eclipse-temurin:17-jre-jammy
ENV HOME=/opt/app
WORKDIR $HOME
ADD hello-0.0.1-SNAPSHOT.jar $HOME
ENTRYPOINT ["java", "-jar", "/opt/app/hello-0.0.1-SNAPSHOT.jar" ]


If you used your own project repository and it didn't contain a Dockerfile, you will need to create a new Dockerfile.


To create a new Dockerfile, execute the following command, which will create the new file.

sudo touch Dockerfile


Then you can fill this file with a sequence of commands that describe how to build a containerized application environment. These commands include actions like copying files into the image, installing software, setting environment variables, and configuring the container.


To fill the Dockerfile with these commands, execute the following command.

vim Dockerfile

The Dockerfile is ready to use.


Step 7: Login Docker

Now that your Dockerfile is prepared for use, proceed by copying your project's JAR artifact from the **"JenkinsServer"**EC2 instance and pasting it onto the "AnsibleServer" EC2 instance. It is important to note that this transfer will be automated through the pipeline further.

By completing this step, you'll be ready to test your Dockerfile along with the Docker environment you've set up.


Before you begin testing, make sure to authenticate yourself on Dockerhub. Execute the following command.

docker login


This command will prompt you to provide your Dockerhub login credentials, including your username and password.

The screenshot of successful docker login in "AnsibleServer" EC2 instance


With this, you have completed the process of logging into Docker and are now ready to proceed with testing.

Step 8: Testing the Docker environment and Dockerfile

With your successful login to Dockerhub completed, you are now ready to begin testing the Dockerfile you have prepared.


Execute this command to create a docker image.

docker build -t hello:latest .


Next, execute the subsequent command to establish a tag that will facilitate the image's upload to Dockerhub:

docker tag hello:latest zufarexplainedit/hello:latest


Finally, proceed to push the Docker image to Dockerhub through the execution of this command.

docker push zufarexplainedit/hello:latest


Following these steps, navigate to your Dockerhub account to verify whether you can see a new image or not.

The screenshot of Dockerhub account with the new image added


You should now observe that the image has been effectively added. This outcome confirms the successful installation of the Docker environment and that your Dockerfile is correct.



[Module 6]: Ansible

Now let us configure the Ansible Server on the EC2 Virtual Server instance.


Step 1: Create an AWS EC2 Virtual Server instance

You need a virtual server to run Ansible.


Follow instructions from [Module 1]: AWS EC2 Virtual Server section of this tutorial to finish this step and create an EC2 virtual server instance for Ansible.

Do not forget to add a security group setup. It allows Ansible and SSH to work on port 8080 and 22 respectively.


Use the name “AnsibleServer” to distinguish your EC2 Virtual Server instance.

You can reuse “CI_CD_Pipeline” security group and “CI_CD_Pipeline_Key_Pair“ for a new “AnsibleServer” EC2 instance.


Step 2: Connect to an AWS EC2 Virtual Server instance

Go to AWS Console home page → EC2 Management Console Dashboard → Instances → AnsibleServer.


Then click the “Connect” button.

The screenshot of AWS web page with the pointer to "Connect" button


Then you will see this web page. You should again click the “Connect” button.


The screenshot of AWS "Connect to Instance" web page with the pointer to "Connect" button


Now you can see the EC2 virtual server instance online terminal.

The screenshot of AWS EC2 Virtual Server instance online terminal


Now let’s configure Ansible Server on EC2 virtual server instance.

Step 3: Change the hostname of “AnsibleServer” AWS EC2 Virtual Server instance

The first thing you need to do when you want to configure AnsibleServer on EC2 virtual server instance is changing its hostname.


Let’s do it. Execute this command to open hostname file:

sudo vi /etc/hostname


You should see something like this:

The screenshot of AWS EC2 Virtual Server instance with hostname file


Replace this hostname with “ansible-server”. Then, reboot it.

sudo init 6



The screenshot of AWS EC2 Virtual Server instance terminal with the pointer to hostname


Step 4: Add and configure a new user in “AnsibleServer” AWS EC2 Virtual Server instance

Now let’s add a new ansible-admin user to the AWS EC2 Virtual Server instance.

To do that use this command:


sudo useradd ansible-admin


Then, set the password for ansible-admin user.

sudo passwd ansible-admin


Also, you need to configure user privileges by editing the sudoers file.

sudo visudo


Add “ansible-admin ALL=(ALL) ALL” to this sudoers file.

The screenshot of AWS EC2 Virtual Server instance terminal with the pointer to admin privileges


Also, you need to edit /etc/ssh/sshd_config file to enable PasswordAuthentication.

sudo vi /etc/ssh/sshd_config


The screenshot of AWS EC2 Virtual Server instance terminal with the pointer to admin settings


Then you need to reload the service to confirm these changes.

sudo service sshd reload


As a result of executing this command, you will see:


The screenshot of AWS EC2 Virtual Server instance terminal with the pointer to sshd reload result


Now you can use this command to avoid adding sudo for all further commands.

sudo su - ansible-admin


Step 5: Generate key in an AWS EC2 Virtual Server instance

You are planning to manage remote servers such as K8s EC2 virtual server instances further in this article. That is why you need to set up SSH keys.

ssh-keygen


As a result of executing this command, you will see:

The screenshot of AWS EC2 Virtual Server instance terminal with the pointer to ssh-keygen result


Now SSH keys are generated and ready to use.

Step 6: Install Ansible

Now you can install Ansible on your “AnsibleServer” EC2 virtual server instance.

Let’s do it.


Execute this command to install Ansible.

sudo amazon-linux-extras install ansible2


To verify Ansible, use this command:

ansible --version


As a result of executing this command, you will see:

The screenshot of AWS EC2 Virtual Server instance terminal with the pointer to sudo yum install ansible  result


Step 7: Install Jenkins “Publish over SSH“ plugin on JenkinsServer EC2 instance

As Ansible is installed on your “AnsibleServer” EC2 virtual server instance, you can configure Jenkins to integrate it with Ansible. You need to install the “Publish over SSH” plugin to integrate Jenkins with the EC2 Virtual Server instance where Ansible is installed and with other EC2 Virtual Server instances where Kubernetes is installed.


Go to “Dashboard” → “Manage Jenkins” → “Configure System” → “Available plugins”.

Then enter “Publish over SSH“ in the search box.


The screenshot of Jenkins installed on AWS EC2 Virtual Server with the pointer to "Available plugins" web page


Click the button “Install without restart”. Wait for the end of the downloading process.


The screenshot of Jenkins installed on AWS EC2 Virtual Server with the pointer to "Download progress" web page



Now the “Publish over SSH” plugin is installed on the Jenkins EC2 Virtual Server instance.


Step 8: Configure Jenkins “Publish over SSH“ plugin

With the successful installation of the Apache Maven Jenkins plugin, you are now able to utilize this plugin within the pipeline which you created and updated in modules 2 and 3.


To do so, follow these steps:


Go to “Dashboard“ → “Manage Jenkins” → “Configure System” → “Publish over SSH”.

The screenshot of AWS EC2 Virtual Server instance terminal with the "Publish over SSH" plugin


Enter all required data as it is on the screenshot, including hostname, username, and private key (or password if applicable).


The screenshot of AWS EC2 Virtual Server instance terminal with the "Publish over SSH" plugin


Then click the “Apply” and “Save” buttons.


Here you have finished configuring the “Publish over SSH“ Jenkins plugin.


Next, click “Test Configuration” to validate that the plugin is working correctly.



The screenshot of the "Publish over SSH" plugin with the button "Test Configuration"


On the left side you can see that the test plugin configuration status is “Success”. It means the plugin configuration is correct.


Step 9: Create new Docker directory in AnsibleServer

You need to make a new folder on the AnsibleServer EC2 instance where the project JAR will be stored. This jar will be used for creating a Docker image later.


Let’s start.


Go to “/opt” folder in AnsibleServer EC2 instance.

cd /opt


Create a new folder “docker” there.

sudo mkdir docker


Give privileges to this “docker” folder.

sudo chown ansible-admin:ansible-admin docker


Now, check the “docker” folder privileges by executing this command.

ll


You can see that the “docker” folder is accessible with the “ansible-admin” user.


The screenshot of "docker" folder in "AnsibleServer" EC2 instance


Step 10: Integrate “Publish over SSH“ Github plugin into the pipeline


Now as “Publish over SSH“ Github plugin is installed and configured, you're now able to integrate it into the pipeline which you created in the “[module 2]: Jenkins Server” to transfer a project jar artifact from “JenkinsServer” to “AnsibleServer”.


Well, to integrate “Publish over SSH“ Github plugin into the pipeline you need to follow these steps:


  1. Navigate to “Dashboard“ → “CI_CD_Pipeline“ → “Configure“ → “Post-build Actions”.
  2. Click “Add post-build action” button.
  3. Choose “Send build artifacts over SSH” option.
  4. Add “AnsibleServer” into “Name” input in “SSH Server” section**.**
  5. Add  “target/*.jar” into “Source files” input in “Transfer Set” section**.**
  6. Add  “target/” into “Remove prefix” input in “Transfer Set” section**.**
  7. Add  “//opt/docker/” into “Remote directory” input in “Transfer Set” section**.**
  8. For now, simply put an empty string in the 'Exec command' input under the 'Transfer Set' section.



The screenshot of "Send build artifact over SSH" section in the pipeline configuration


Finally, you should click “Apply” and “Save” buttons to finish the integration “Publish over SSH“ plugin with the pipeline.


Step 11: Test “Publish over SSH“ Github plugin integrated into the pipeline

Now you can use your updated pipeline to transfer a project jar artifact from “JenkinsServer” to “AnsibleServer”. To do that you need to click the “Build Now” button. As a result you will see a successful job result in the build history.


If you open your “AnsibleServer” AWS EC2 terminal. You can check that the pipeline works well.

Just use this command.


cd /opt/docker


This way you can see the JAR artifact, indicating the successful build of your project from GitHub.

The screenshot of /opt/docker directory with the project jar artifact


Step 12: Configure Ansible hosts

When you run an Ansible playbook, you specify the hosts it should run on. You can do this in two ways:


  1. Specify hosts directly in the playbook: In your playbook, you can set the hosts parameter to a list of IP addresses or hostnames.
  2. Use an inventory file: Ansible allows you to define a list of hosts in an inventory file and reference this file when running your playbook. The default inventory file is /etc/ansible/hosts.


By editing /etc/ansible/hosts, you can easily manage groups of hosts without having to write out their IP addresses each time you run a playbook.


Let’s find out the AnsibleServer EC2 instance host by executing the following command.

sudo ifconfig


The screenshot of the network interface setting of AnsibleServer EC2 instance


After you find out AnsibleServer EC2 instance host, you can add it to the Ansible hosts file by executing the following command.


sudo vi /etc/ansible/hosts


You can also add “[ansible]” as a reference

The screenshot of Ansible hosts file


If you're managing a cluster of servers and you want to apply a playbook to all of them, instead of specifying each server's IP address in the playbook, you can simply add all the servers to a group in the inventory file and then specify the group in the playbook.


Step 13: Configure Passwordless SSH authentication to localhost for Ansible

Ansible is designed for automating tasks on remote servers. Passwordless SSH authentication empowers Ansible to connect to those servers without the need for manual password entry.

Execute this command to create a secure connection from your computer to another computer (like the one at IP address 172.31.34.41), using the ansible-admin user's SSH key.


sudo ssh-copy-id -i /home/{your user name}/.ssh/id_rsa.pub {your user name}@{your host address}


In my case, it looks like this.

sudo ssh-copy-id -i /home/ansible-admin/.ssh/id_rsa.pub [email protected]


The screenshot of the successful passwordless ssh authentication installation result


Now you can see “Number of key(s) added: 1”. It means that the passwordless SSH authentication installation was successfully completed.

Step 14: Create a new Ansible playbook for Docker tasks

Now that Ansible is all set up and good to go, you can make a new Ansible playbook for your pipeline. This playbook will let Ansible create and send a new Docker image to Dockerhub.

Here's how you can do it:


  1. Start by creating a new Ansible playbook file. Just use this command.
touch hello-app.yml


  1. Then, edit the newly made hello-app.yml file. Open it up for editing with this command.
vi hello-app.yml


  1. Inside the file, type in the following stuff.
---
- hosts: ansible
  user: root

  tasks:
    - name: create docker image
      command: docker build -t hello:latest .
      args:
        chdir: /opt/docker

    - name: create tag to push image onto dockerhub
      command: docker tag hello:latest zufarexplainedit/hello:latest

    - name: push docker image onto dockerhub
      command: docker push zufarexplainedit/hello:latest

The Ansible playbook for Docker tasks is ready to use.

Step 13: Test the Ansible playbook with Docker tasks

With Ansible, Ansible playbook, AnsibleServer, and JenkinsServer all properly configured, it is time to test the Ansible playbook.


Navigate to the location of your Ansible playbook.

cd /opt/docker


Then, execute the following command.

sudo -u ansible-admin ansible-playbook /opt/docker/hello-app.yml


Upon completion, you will see the successful execution outcome of your Ansible playbook.

The screenshot of the successful execution result of the ansible playbook for docker tasks


Furthermore, take a moment to visit your Dockerhub account and verify whether a new image is now visible.


The screenshot of Dockerhub account with the new image added


You should see the newly added image. This outcome confirms that your Ansible playbook is correct.


Step 14: Integrate Ansible Docker tasks into the pipeline

Now as “Publish over SSH“ Github plugin, Ansible and Docker are installed and configured, you're now able to integrate them all into the pipeline which you created in the “[module 2]: Jenkins Server” to transfer a project jar artifact from “JenkinsServer” to “AnsibleServer” and then build a new Docker image from your project and then push this Docker image onto Dockerhub.


To achieve it you need to follow these steps:

  1. Navigate to “Dashboard“ → “CI_CD_Pipeline“ → “Configure“ → “Post-build Actions” → “Send build artifacts over SSH” .
  2. Add “sudo -u ansible-admin ansible-playbook /opt/docker/hello-app.yml” command into “Exec command” input.


The screenshot of "Send build artifact over SSH" section in the pipeline configuration


Finally, click “Apply” and “Save” buttons to finish the integration Ansible Docker tasks with the pipeline.

Step 15: Test “Ansible playbook with Docker tasks“ integrated into the pipeline

Now you can test your upgraded pipeline to seamlessly transfer a project jar artifact from “JenkinsServer” to “AnsibleServer” then build a new Docker image from your project and then push this Docker image onto Dockerhub. To do that you need to click the “Build Now” button. As a result you will see a successful job result in the build history.


Furthermore, take a moment to visit your Dockerhub account and verify whether a new image is now visible.


The screenshot of Dockerhub account with the new image added


You should see the newly added image. This outcome confirms that your Ansible playbook with Docker tasks was successfully integrated into the pipeline.


[Module 7]: Kubernetes

Now let’s configure K8s on the EC2 instance. You are going to create a new EC2 instance and install their kubectl command-line tool for interacting with a Kubernetes cluster further.


Step 1: Launch an AWS EC2 Virtual Server instance

Use instructions from “Launch an AWS EC2 Virtual Server instance” section of this tutorial to finish this step.


Do not forget to add a security group setup. It allows all tools and SSH to work on port 8080 and 22 respectively.


Use the name “K8sServer” to distinguish your EC2 Virtual Server instance.

You can reuse “CI_CD_Pipeline” security group and “CI_CD_Pipeline_Key_Pair“ for a new “K8sServer” EC2 instance.


Step 2: Connect to an AWS EC2 Virtual Server instance

Click the “Connect” button.

The screenshot of AWS web page with the pointer to "Connect" button


Now you can see the EC2 Virtual Server instance online terminal.

The screenshot of AWS EC2 Virtual Server instance online terminal


Step 3: Change the hostname of “KubernetesServer” AWS EC2 Virtual Server instance

The first thing you need to do when you want to configure KuberenetesServer on EC2 virtual server instance is to change its hostname.


Let’s do it. Execute this command to open hostname file:

sudo vi /etc/hostname


You should see something like this.

The screenshot of AWS EC2 Virtual Server instance with hostname file


Replace this hostname with “kubernetes-server” and then reboot it.

sudo init 6


You will hostname was changed.

The screenshot of AWS EC2 Virtual Server instance terminal with the pointer to hostname


Step 4: Check AWS CLI version

Use this command to check the AWS version.

aws --version


This way you can see your current aws-cli version.

The screenshot of AWS EC2 Virtual Server instance online terminal with aws version command result


If you can see version aws-cli/1.18, you should download the latest version.


Step 5: Update AWS CLI

Now as you found out that you have an old aws-cli version on your EC2 instance you need to update it. To that go to AWS → Documentation → AWS Command Line Interface → User Guide for Version 2.


The screenshot of AWS EC2 Virtual Server instance webpage with User Guide for Version 2


Copy-paste the curl command.


First, execute this command to download awscli version 2.

curl "https://awscli.amazonaws.com/awscli-exe-linux-x86_64.zip" -o "awscliv2.zip"

Wait for the downloading process to commence.


You should see something like this.

The screenshot of AWS EC2 Virtual Server instance online terminal with downloading aws version 2 result


Second, you need to execute this command to unzip awscli version 2 archive.

unzip awscliv2.zip


Third, you should execute this command to install awscli version 2.

sudo ./aws/install


Then, reload the Kubernetes EC2 Virtual Server instance online terminal.


Next, use this command to check the AWS version

aws --version


You can see that aws cli has aws-cli/2.

The screenshot of AWS EC2 Virtual Server instance online terminal with aws version coommand result


Step 6: Install kubectl

Kubectl is a fundamental command-line tool for interacting with any Kubernetes cluster, regardless of the underlying infrastructure. It allows you to manage resources, deploy applications, configure networking, access logs, and perform various other tasks within a Kubernetes cluster.


Now you need to install kubectl command-line tool for interacting with a Kubernetes cluster further. To that you need to go to AWSDocumentationAmazon EKSUser GuideInstalling or updating kubectlLinux.


Or just click the link https://docs.aws.amazon.com/eks/latest/userguide/install-kubectl.html.


The screenshot of AWS EKS User Guide



First, execute this command to download kubectl.

curl -O https://s3.us-west-2.amazonaws.com/amazon-eks/1.27.1/2023-04-19/bin/linux/amd64/kubectl


Wait for the downloading process.


You will see something like this.

The screenshot of AWS EC2 Virtual Server instance online terminal with downloading kubectl result


Give permission to kubectl.

chmod +x kubectl


Move kubectl to /usr/local/bin folder.

sudo mv kubectl /usr/local/bin


Check the version of kubectl.

kubectl version --output=yaml


Step 7: Install eksctl

Eksctl is an another command-line tool which is tailored specifically to the Amazon EKS service. Eksctl can be used to create AWS EKS clusters, manage node groups, and perform tasks specific to EKS, such as integrating with IAM roles and other AWS services by abstracting away much of the AWS infrastructure setup and management.


Execute the command to download kubectl.

curl --silent --location "https://github.com/weaveworks/eksctl/releases/latest/download/eksctl_$(uname -s)_amd64.tar.gz" | tar xz -C /tmp


Move eksctl to /usr/local/bin folder.

sudo mv /tmp/eksctl /usr/local/bin


Check the version of eksctl.

eksctl version


You should see the version

The screenshot of AWS EC2 Virtual Server instance online terminal with eksctl version


Step 8: Create IAM Role for eksctl

You need to create an IAM role and attach it to your “KubernetesServer” EC2 instance.

To do that you need to find EC2 in the search box.


Choose EC2 Virtual Server by clicking the link https://us-east-1.console.aws.amazon.com/ec2/.

The screenshot of AWS web page with the pointer to "IAM"


Go to IAM DashboardRoles.

The screenshot of AWS web page with the pointer to "IAM Roles"


Click the button “Create role” on the IAM roles web page.


Then choose “AWS service” , “EC2”. And the click “Next” button.

The screenshot of AWS web page with the pointer to "IAM Roles configuration"


Then, find “AmazonEC2FullAccess”, “AmazonEC2FullAccess“, “IAMFullAccess“, “AWSCloudFormationFullAccess“ in the search box and then click the “Add permissions” button.


And then click the “Next” button.

The screenshot of AWS web page with the pointer to AdministratorAccess permission

Then type “Eksctl_Role” into “Role name” input.

And the click “Create role” button.

The screenshot of AWS web page with the pointer to  permission role configuration


The role is created finally.


Step 9: Connect IAM Role with eksctl

Go to the AWS EC2 instance web page. Choose “KuberbetesServer”. Then click “Actions” → “Security” → “Modify IAM Role”.


The screenshot of AWS web page with the pointer to KubernetesServer Security button



Choose “Eksctl_Role” and then click the “Update IAM role” button.


The screenshot of AWS web page with the pointer to  Elsctl_Role IAM role


Now your IAM Role is connected with your “EKS_Server” and eksctl tool.

Step 10: Create eksctl cluster


An Amazon EKS (Elastic Kubernetes Service) cluster is a managed Kubernetes environment on AWS, automating intricate infrastructure tasks like setup, scaling, and maintenance. It's essential as it provides an efficient, secure, and AWS-optimized platform for deploying, managing, and scaling containerized applications, streamlining operations and freeing developers to focus on coding rather than managing underlying infrastructure.


Now, it's time to set up your EKS cluster.


To achieve this, follow these steps:


  1. Modify the following command with your specific information.
eksctl create cluster --name cluster-name  \
--region region-name \
--node-type instance-type \
--nodes-min 2 \
--nodes-max 2 \
--zones <AZ-1>,<AZ-2>


For example, in my case, it looks like this.

eksctl create cluster --name zufarexplainedit  \
--region eu-north-1 \
--node-type t3.micro


  1. Execute the modified command and patiently await the completion of the cluster creation process. You will notice that the EKS cluster status is indicated as "creating" on the AWS CloudFormation web page.


The screenshot of AWS web page with the pointer to AWS CloudFormation where you can see EKS cluster "creating" status


The cluster creation procedure typically takes around 20 minutes. Once completed, the terminal will display the outcome of the process.


The screenshot of AWS web page with the pointer to AWS EC2 terminal where you can see EKS cluster creation result


Furthermore, you can verify the successful EKS cluster creation status on the AWS CloudFormation web page.


The screenshot of AWS web page with the pointer to AWS CloudFormation where you can see EKS cluster creation result


Step 11: Create Kubernetes Deployment yaml file

A Kubernetes Deployment YAML file is a configuration script written in YAML format that defines how to manage and maintain a specific application or service within a Kubernetes cluster. It encapsulates instructions for orchestrating the deployment, scaling, updating, and monitoring of containers running the application. This file includes details such as the container image, the desired number of replicas, resource limits, environment variables, networking settings, and more. When applied to a Kubernetes cluster, the Deployment YAML file ensures the desired state of the application, automatically managing the creation, scaling, and recovery of containers to maintain the desired level of availability and reliability.


Now, as Kubernetes cluster, eksctl, kubectl are installed and configured, you can create a Kubernetes Deployment yaml file.


You can do that by executing the following command.

touch hello-app-deployment.yaml


Then, edit this file by executing the following command.

vi hello-app-deployment.yaml


Add this content to the hello-app-deployment.yaml.

apiVersion: apps/v1
kind: Deployment
metadata:
  name: zufarexplainedit-hello-app
  labels:
     app: hello-app

spec:
  replicas: 2
  selector:
    matchLabels:
      app: hello-app

  template:
    metadata:
      labels:
        app: hello-app
    spec:
      containers:
      - name: hello-app
        image: zufarexplainedit/hello
        imagePullPolicy: Always
        ports:
        - containerPort: 8080
  strategy:
    type: RollingUpdate
    rollingUpdate:
      maxSurge: 1
      maxUnavailable: 1


Now hello-app-deployment.yaml is created and ready to use.


Step 12: Create Kubernetes Service yaml file

A Kubernetes Service YAML file is a configuration script written in YAML format that defines a network abstraction for a set of pods, allowing them to be accessed consistently within a Kubernetes cluster. This file outlines how the service should be discovered, accessed, and load-balanced by other services or external clients. It includes specifications like the service type (ClusterIP, NodePort, LoadBalancer), port numbers, selectors to identify pods, and more. When applied to a Kubernetes cluster, the Service YAML file creates a virtual IP and port that routes traffic to the appropriate pods, abstracting the underlying pod changes and providing a stable endpoint for communication, enabling seamless connectivity and dynamic scaling.


As Kubernetes cluster, eksctl, kubectl are installed and configured, you can create Kubernetes Service yaml file.


To do that you need to create a Kubernetes Service yaml file by executing the following command.

touch hello-app-service.yaml


Then, edit this file by executing the following command.

vi hello-app-service.yaml


Add this content to the hello-app-deployment.yaml.

apiVersion: v1
kind: Service
metadata:
  name: zufarexplainedit-hello-app-service
  labels:
    app: hello-app
spec:
  selector:
    app: hello-app

  ports:
    - port: 8080
      targetPort: 8080

  type: LoadBalancer

Now hello-app-service.yaml is created and ready to use.


Step 13: Test Kubernetes cluster using kubectl

With your Kubernetes EKS cluster successfully installed, and configured, and your Kubernetes service and deployment files ready, it's time to put things to the test using kubectl commands.


  1. Apply Deployment.

    Use the following command to apply the deployment configuration.

kubectl apply -f hello-app-deployment.yaml

This will create a deployment with the specified number of replicas and a rolling update strategy, ensuring your application's availability and manageability.


2. Apply Service.

Next, apply the service configuration.

kubectl apply -f hello-app-service.yaml

This will set up a LoadBalancer type service, exposing your application to the internet.

Note that it might take a short while for the LoadBalancer to be provisioned and acquire an external IP address.


  1. Check LoadBalancer Status.

    Monitor the status of your service using.

kubectl get service zufarexplainedit-hello-app-service

When an external IP is assigned, you're almost ready to access your application.


  1. Access Your Application.

    Using a web browser, enter the assigned external IP address followed by :8080. After a brief moment, the page will load, displaying the "HelloWorld" message. Keep in mind that the initial loading might take a few seconds.


    The screenshot of Hello app web page


Cleaning Up with kubectl Commands

When you need to tidy up resources within your Kubernetes environment, you can use the following kubectl commands to effectively remove deployments, pods, and services.


1. Delete All Deployments.

To delete all deployments, you can use the following command.

kubectl delete deployments --all

This action ensures that no active deployment instances are left in your cluster.


2. Delete All Pods.

If you need to delete all pods, whether they are managed by a deployment or not, you can use the following command.

kubectl delete pods --all

Clearing pods can help reset your cluster state or prepare for new deployments.


3. Delete All Services.

To clean up services that expose your applications to the network, you can use the following command.

kubectl delete services --all

Removing services may involve downtime, so consider the implications before proceeding.

Deleting an Amazon EKS Cluster

To remove all the resources associated with the specified Amazon EKS cluster created with eksctl, including worker nodes, networking components, and other resources, you can use the following command.

eksctl delete cluster --name {your cluster name} --region {your region name}

For me it is.

eksctl delete cluster --name zufarexplainedit --region eu-north-1

Make sure you are certain about stopping the cluster, as this action is irreversible and will result in data loss.



Step 14: Add and configure a new user in “KubernetesServer” AWS EC2 Virtual Server instance

Now let’s add a new ansible-admin user to “KubernetesServer” AWS EC2 Virtual Server instance.


To do that use this command.

sudo useradd ansible-admin


Then, set the password for ansible-admin user.

sudo passwd ansible-admin


Also, you need to configure user privileges by editing the sudoers file.

sudo visudo


Add “ansible-admin ALL=(ALL) ALL” to this sudoers file.

The screenshot of AWS EC2 Virtual Server instance terminal with the pointer to admin privileges


Also, you need to edit /etc/ssh/sshd_config file to enable PasswordAuthentication.

sudo vi /etc/ssh/sshd_config


The screenshot of AWS EC2 Virtual Server instance terminal with the pointer to admin settings


Then you need to reload the service to make these changes.

sudo service sshd reload


As a result of executing this command, you will see:

The screenshot of AWS EC2 Virtual Server instance terminal with the pointer to sshd reload result


Now you can use this command to avoid adding sudo for all further commands.

sudo su - ansible-admin


Step 15: Generate key in an AWS EC2 Virtual Server instance

You are planning to manage remote servers such as K8s EC2 virtual server instance further in this article. That is why you need to set up SSH keys.


ssh-keygen


As a result of executing this command, you will see:

The screenshot of AWS EC2 Virtual Server instance terminal with the pointer to ssh-keygen result


Now SSH keys are generated and ready to use.

Step 16: Configure Passwordless SSH authentication to localhost for Ansible

Ansible is designed for automating tasks on remote servers. Passwordless SSH authentication empowers Ansible to connect to those servers without the need for manual password entry.

Execute this command to create a secure connection from your computer to another computer (like the one at IP address 172.31.34.41), using the ansible-admin user's SSH key.


sudo ssh-copy-id -i /home/{your user name}/.ssh/id_rsa.pub {your user name}@{your host address}


In my case, it looks like this.

sudo ssh-copy-id -i /home/ansible-admin/.ssh/id_rsa.pub [email protected]


The screenshot of the successful passwordless ssh authentication installation result


Now you can see “Number of key(s) added: 1”. It means that the passwordless SSH authentication installation was successfully completed.


Step 17: Configure Ansible hosts in AnsibleServer EC2 instance

When you run an Ansible playbook, you specify the hosts it should run on. In this step you need to specify KubernetesServer EC2 instance host. To do that you need to repeat the same steps which you passed in “[Module 6]: Ansible”.


Let’s find out the KubernetesServer EC2 instance host by executing the following command.

sudo ifconfig


The screenshot of "ifconfig" file


After you find the KubernetesServer EC2 instance host, you can add it to the Ansible hosts file by executing the following command.

sudo vi /etc/ansible/hosts


The screenshot of "hosts" files with ansible and kubernetes hosts


You can also add “[kubernetes]” as a reference

Step 18: Create a new Ansible playbook for Kubernetes tasks

Now that Kubernetes is all setup and good to go, you can make a new Ansible playbook with Kubernetes tasks for your pipeline. This playbook will let Ansible run your app on the Kubernetes cluster with kubectl commands.


Here's how you can do it:


  1. Start by creating a new Ansible playbook file. Just use this command.
touch kubernetes-hello-app.yml


  1. Then, edit the newly made hello-app.yml file. Open it up for editing with this command.
vi kubernetes-hello-app.yml


  1. Inside the file, type in the following:
---
- hosts: kubernetes

  tasks:
    - name: deploy regapp on kubernetes
      command: kubectl apply -f hello-app-deployment.yaml

    - name: create service for regapp
      command: kubectl apply -f hello-app-service.yaml

    - name: update deployment with new pods if image updated in docker hub
      command: kubectl rollout restart deployment.apps/zufarexplainedit-hello-app

The Ansible playbook for Kubernetes tasks is ready to use.


Step 19: Integrate a new Ansible playbook for Kubernetes tasks with Jenkins

Now that Kubernetes, Ansible, and Ansible playbook for Kubernetes tasks are all set up and good to go, you can integrate it with Jenkins.


  1. Go to JenkinsServer → Jenkins dashboard → New Item.

  2. Create new Jenkins Freestyle project with the name “CD-Job”.


    The screenshot of a new Jenkins freestyle project "CD-Job"


  3. Click “OK” button.

  4. Go to “Post-build Actions” section.

  5. Click the “Add post-build action” button.

  6. Choose “Send build artifacts over SSH” option.

  7. Choose “AnsibleServer” as SSH Server.

  8. Add this command to “exec command” input.


sudo -u ansible-admin ansible-playbook /opt/docker/kubernetes-hello-app.yml


  1. Click “Apply” and “Save” buttons.

  2. Go to Jenkins dashboard → “CI_CD_Pipeline” → Configure → “Post-build Actions” section.

  3. Click the “Add post-build action” button.

  4. Choose “Build other projects” option.

  5. Go to “Build other projects” section.

  6. Choose “Trigger only if build is stable” option.

  7. Add “CD-Job” to “Project to build” input.



    The screenshot of "Build other projects" section


  8. Click “Apply” and “Save” buttons.


Now you can consider that the pipeline is completely finished and ready to use.


Step 20: Testing the Final Pipeline Version

Now is the time to put the final pipeline version to the test.


Navigate to Jenkins → Jenkins dashboard → "CI_CD_Pipeline".


Click the "Build Now" button.


To see the results, review the build console logs.


The screenshot of the build console logs


You will notice that the "CD-Job" was triggered in the build console logs, and the final status is marked as SUCCESS.

4

Moreover, you can head to Dockerhub to confirm the addition of the new Docker image.

And finally, you can access your application using a web browser. Enter the assigned external IP address followed by ":8080". After a brief moment, the page will load, showing the "HelloWorld" message.


Conclusion

Well done on setting up this modern CI/CD pipeline!

You've done an awesome job, and you're a real hero!


Thanks for all your effort!




About the author

Zufar Sunagatov is an experienced senior software engineer who is passionate about designing modern software systems.


Zufar Sunagatov
