Django, Celery, Redis and Flower Implementation

by Abhishek Kumar SinghApril 29th, 2020

Too Long; Didn't Read

Django, Celery, Redis and Flower Implementation Implementation Implementation. Celery is a Django-based tool to integrate Django with Celery and Redis. The Celery-Redis integration is a free-form solution to solve one of the major global issues. The celery-redis integration was a python python package which was a Python problem before. We’ve done the celery integration with Django. This is what we installed with celery. It’s a python package that helps us to talk about this server.

featured image - Django, Celery, Redis and Flower Implementation

Here I’m assuming you already have your basic Django project setup. And, already know what Celery is? if not, I’ll suggest getting a basic understanding of it here. So let’s just directly jump into the steps.

Please follow the comments to get a basic understanding of the code.

Install celery into your project. As celery also need a default broker (a solution to send and receive messages, and this comes in the form of separate service called a message broker). Check the list of available brokers: BROKERS. So you can directly install the celery bundle with the broker. Bundles available.

(env)$ pip install "celery[redis]"

Once installed. Head to the project folder which contains

settings.py

and create a new file called

celery.py

and put the following code into it.

import os

from celery import Celery

# set the default Django settings module for the 'celery' program.
os.environ.setdefault('DJANGO_SETTINGS_MODULE', 'meupBackend.settings')

app = Celery('meupBackend', backend='redis', broker='redis://localhost:6379')

# Using a string here means the worker doesn't have to serialize
# the configuration object to child processes.
# - namespace='CELERY' means all celery-related configuration keys
#   should have a `CELERY_` prefix.
app.config_from_object('django.conf:settings', namespace='CELERY')

# Load task modules from all registered Django app configs.
app.autodiscover_tasks()


@app.task(bind=True)
def debug_task(self):
    print('Request: {0!r}'.format(self.request))

and now head over to

__init__.py

of the same folder and put the following code.

from __future__ import absolute_import, unicode_literals

# This will make sure the app is always imported when
# Django starts so that shared_task will use this app.
from .celery import app as celery_app

__all__ = ('celery_app',)

and now head over to settings.py and insert the following code into respective places.

### settings.py

BROKER_URL = 'redis://localhost:6379'
CELERY_RESULT_BACKEND = 'redis://localhost:6379'
CELERY_ACCEPT_CONTENT = ['application/json']
CELERY_TASK_SERIALIZER = 'json'
CELERY_RESULT_SERIALIZER = 'json'

INSTALLED_APPS = [
    # others app
    'celery',
    'django_celery_results',
    'django_celery_beat',
]


"""
django_celery_results:
This extension enables you to store Celery task results using the Django ORM.
"""
"""
django_celery_beat:
This extension enables you to store the periodic task schedule in the database.
The periodic tasks can be managed from the Django Admin interface, where you can create, edit and delete periodic tasks and how often they should run.
"""

and now, add a basic task somewhere in your app.

### tasks.py (in any of your app)


from __future__ import absolute_import
from celery import shared_task


@shared_task
def test(param):
    return 'The test task executed with argument "%s" ' % param

So, up until now. We’ve done the celery integration with Django. Now, go to your terminal and install redis server. This is mainly the broker server, what we installed with celery before was a python package which helps us to talk 😅 to this server.

### Terminal

(env)$ brew install redis

# once installed, run:

(env)$ redis-server


# Terminal 2, open another terminal or tab

(env)$ redis-cli ping
pong

If you get the pong response, then you’re fine to move forward, can quit the server and close the terminals.

If you’re on Windows and Linux, please check out how you can install the Redis here: https://redis.io/download. Now… run:

(env)$ python manage.py migrate

This will reflect the migrations of django_celery_result and django_celery_beat . Now install the flower with the following command.

(env)$ pip install flower

Once installed. Open 3 terminals and run:

Terminal 1:

(env)$ redis-server

Terminal 2:

$ python manage.py runserver

Terminal 3:

(env)$ flower -A meup ## here `meup` is a project name

Now your project will be running on

localhost:8000

, Redis will be running on port

, and flower will be running on

 localhost:5000

Please make sure your Redis server is running on a port 6379 or it’ll be showing the port number in the command line when it got started. So put that port number into you Redis server config into celery configurations file.

🙏

Previously published at https://medium.com/@abheist/django-celery-redis-and-flower-9b5a4d876870
