Dive Into GraphQL Part II: Anatomy of a GraphQL Query

In of the , I’ve explained why REST isn’t such a good fit for today’s web and mobile applications. REST makes applications slow, harder and more expensive to develop, and too limited in functionality. We need a new hero, an architecture that allows to: the first post Dive Into GraphQL Series Query aggregates of resources (e.g. tweets and profile, in one round trip), even from different domains Query an explicit list of fields, never a complete resource Provide a schema describing the syntax of the request and response Be a standard, but not too tied to the HTTP protocol Support Publish/Subscribe scenarios out of the box Shift the emphasis from the server to the client. My conviction is that , a query language invented by , is a great candidate. This conviction is based on several months of development with GraphQL, and is shared by many developers at Marmelab. I’ll explain what GraphQL is in this post. GraphQL Facebook But first, let’s bust a few misconceptions about GraphQL. What GraphQL Is Not First and foremost, GraphQL is not a query language for graph databases. That would be . There a concept of graph in GraphQL, but learners don’t understand it until they’re halfway through the docs (and I’ll explain it in the next post). In the meantime, many curious developers give up, thinking this doesn’t concern them if they use a relational or a document database. Gremlin is So in my opinion, GraphQL’s biggest flaw is its name. Any other name would have been better, like, why not, “Caramel”. Not that it can’t happen to anybody else: I named “ ” a React library that can work with any REST backend. So let’s make that clear: GraphQL works with any database — relational, key/value store, document, and graph. You can even use it in front of a REST API. admin-on-rest or GraphQL GraphQL is not a React library, it is not even just a JavaScript library. I know, most of the tutorials you’ll find about GraphQL use JavaScript, but it’s only because JS developers tend to write a lot of code, so they want to share it (pun intended). GraphQL is a , with implementations in many languages. You can use GraphQL on the client side in JS, Objective-C or Java. You can use GraphQL on the server side in JS, Go, Python, Ruby, PHP, etc. specification GraphQL is not a transport protocol. You can use GraphQL with any transport — HTTP, WebSockets, you can even send GraphQL queries as text files by Bittorrent if you feel like. That makes it different from REST, which is tied to the HTTP protocol, and built on the HTTP grammar ( , , , etc.). GET POST PUT Following on from that idea, GraphQL doesn’t deal with authentication, authorization, compression, caching, content negotiation, etc. That’s your responsibility. GraphQL intentionally doesn’t include built-in filtering, sorting, computations, or joins. You carefully design all of those yourself to fit the needs of the API consumer, just like REST. Your First GraphQL Query Now, instead of describing what GraphQL , let’s look at what it in comparison with REST. For instance, requesting a single tweet from an API usually looks like the following in REST: is does ----------------------------------- requestGET /tweets/123 HTTP 1.1Host: http://rest.acme.com/----------------------------------- responseHTTP/1.1 200 OKContent-Type: application/json{ "id:" 123, "body": "Lorem Ipsum dolor sit amet", "user_id": 456, "views": 45, "date": "2017-07-14T12:44:17.449Z" // etc.} In GraphQL over HTTP, the equivalent would be: ----------------------------------- requestPOST / HTTP 1.1Host: http://graphql.acme.com/Content-Type: application/graphql{ Tweet(id: 123) { id body date }}----------------------------------- responseHTTP/1.1 200 OKContent-Type: application/json{ "data": { "Tweet": { "id:" "123", "body": "Lorem Ipsum dolor sit amet", "date": "2017-07-14T12:44:17.449Z" } }} There are several things to note from this example: In REST, the API exposes one endpoint per resource ( is such an endpoint), while in GraphQL, there is a single endpoint for the entire API ( in the example) /tweets / Just like REST, the body of a GraphQL response is a JSON object. However, the format of the response is normalized, and the content is always available under a key. data In GraphQL, parameters are passed between parentheses (here: ) and inside the query. (id: 123) In REST, you ask for a complete resource, while in GraphQL, you have to explicitly list the fields you want ( , , and in this example). id body date GraphQL queries use a special query language called… graphql. It looks like JSON but not really. We’ll see that very soon. The GraphQL request uses a special content type application/graphql Unlike REST, GraphQL isn’t tied to HTTP semantics. To read a resource, GraphQL uses a HTTP request. POST If you’re a die hard REST fan, this last point will probably make you cringe. What, using to a resource? Isn't it as criminal as drowning kittens? Here is worse for you: In GraphQL, you can also use to make the same query if you feel like: POST read GET ----------------------------------- requestGET /?query=query%20%7B%20Tweet(id%3A%20123)%20%7Bid%20body%20date%20%7D%7DHost: http://graphql.acme.com/----------------------------------- responseHTTP/1.1 200 OKContent-Type: application/json{ "data": { "Tweet": { "id:" "123", "body": "Lorem Ipsum dolor sit amet", "date": "2017-07-14T12:44:17.449Z" } }} If you feel shocked, please bear with me. In a few minutes, you’ll see how great an idea that is. So yes, GraphQL servers usually don’t care about the HTTP verb. It’s more common to use for everything (read and write queries) because it's more readable in tutorials. As explained earlier, you don't even have to use HTTP at all to communicate with a GraphQL server. POST As a side note, you can see with the request that newlines and tabulations aren't significant in graphql queries. GET GraphQL is Remote Procedure Call, Not Resource-Based In , I introduced the use case of the mobile Twitter home page: the previous post To render this page, the application needs to read the 10 latest tweets, not just one. Here is how you would do it in REST: ----------------------------------- requestGET /tweets/?limit=10&sortField=date&sortOrder=DESC HTTP 1.1Host: http://rest.acme.com/----------------------------------- responseHTTP/1.1 200 OKContent-Type: application/json[ { "id:" 752, "body": "consectetur adipisicing elit", "user_id": 249, "views": 12, "date": "2017-07-15T13:17:42.772Z", // etc. }, { "id:" 123, "body": "Lorem Ipsum dolor sit amet", "user_id": 456, "views": 45, "date": "2017-07-14T12:44:17.449Z" // etc. }, // etc.] In GraphQL, just like you called the query to get one tweet, you usually call the query to get several tweets. But then again, you need to list the fields you want to appear in the response: Tweet Tweets ----------------------------------- requestPOST / HTTP 1.1Host: http://graphql.acme.com/Content-Type: application/graphql{ Tweets(limit: 10, sortField: "date", sortOrder: "DESC") { id body date }}----------------------------------- responseHTTP/1.1 200 OKContent-Type: application/json{ "data": { "Tweets": [ { "id": "752", "body": "consectetur adipisicing elit", "date": "2017-07-15T13:17:42.772Z", }, { "id": "123", "body": "Lorem Ipsum dolor sit amet", "date": "2017-07-14T12:44:17.449Z" }, // etc. ] }} and are query names, defined by the server. As a matter of fact, GraphQL is at its core a Remote Procedure Call (RPC) language: it lets the client call procedures (queries) on the server. That means it's absolutely not limited to CRUD (Create, Retrieve, Update, Delete) scenarios. Tweet Tweets I should warn you though: There is no convention for queries. Some GraphQL servers will use for a list of tweets, others may use , others , etc. I know that , but I still regret that the GraphQL spec didn't take a step further. naming Tweets allTweets getTweetPage naming things is one of the two hard things in computer science Aggregates You may wonder why the GraphQL response contains a key in the response, instead of putting the list of tweets directly under . Well, that's because you can query for several resources at the same time - in a single round trip: Tweets "data" ----------------------------------- requestPOST / HTTP 1.1Host: http://graphql.acme.com/Content-Type: application/graphql{ Tweets(limit: 10, sortField: "date", sortOrder: "DESC") { id body date } User { full_name } NotificationsMeta { count }}----------------------------------- responseHTTP/1.1 200 OKContent-Type: application/json{ "data": { "Tweets": [ { "id": "752", "body": "consectetur adipisicing elit", "date": "2017-07-15T13:17:42.772Z", }, { "id": "123", "body": "Lorem Ipsum dolor sit amet", "date": "2017-07-14T12:44:17.449Z" }, // etc. ], "User": { full_name: "John Doe" }, "NotificationsMeta": { count: 12 } }} In addition to the , I called the query to get the details about the connected user, and the query to get the number of pending notifications. GraphQL lets me aggregate several queries into one HTTP request. Tweets User NotificationsMeta There is still one thing missing, though: the author’s name and avatar for each tweet. In REST, you’d have to wait for the response to the first query to get the for each tweet, then query the endpoint with these ids. This would block the rendering of the page until the second response has returned. In GraphQL, you can query the author directly in the tweet: user_id /users ----------------------------------- requestPOST / HTTP 1.1Host: http://graphql.acme.com/Content-Type: application/graphql{ Tweets(limit: 10, sortField: "date", sortOrder: "DESC") { id body date Author { username full_name avatar_url } } User { full_name } NotificationsMeta { count }}----------------------------------- responseHTTP/1.1 200 OKContent-Type: application/json{ "data": { "Tweets": [ { "id": "752", "body": "consectetur adipisicing elit", "date": "2017-07-15T13:17:42.772Z", "Author": { "username": "alang", "full_name": "Adrian Lang", "avatar_url": "http://avatar.acme.com/02ac660cdda7a52556faf332e80de6d8" } }, { "id": "123", "body": "Lorem Ipsum dolor sit amet", "date": "2017-07-14T12:44:17.449Z", "Author": { "username": "creilly17", "full_name": "Carole Reilly", "avatar_url": "http://avatar.acme.com/5be5ce9aba93c62ea7dcdc8abdd0b26b" } }, // etc. ], "User": { full_name: "John Doe" }, "NotificationsMeta": { count: 12 } }} So GraphQL allows you to group many queries into one, including queries for related resources. That way, you can always get all the data you need for a screen in a single request. Indeed, the last query is enough to render the entire Twitter home page in one roundtrip. Mission accomplished! : If you’re wondering how a GraphQL server works, will answer your questions. It’s a tutorial for building a GraphQL server for a Twitter app. For now, please consider that the server already exists, and free your mind from these server-side considerations. Tip the third post in this series Introspecting a GraphQL Server Wait, how did I know that I could call the , , and queries on the server? I mean, apart from the fact that I'm actually writing this tutorial? To put it otherwise, how do I, a frontend developer, know which queries, and which fields in each query, I can call on a GraphQL backend? Tweets User NotificationsMeta GraphQL answers that requirement by exposing a map of the queries. Every GraphQL server can answer a special query called - it's called the query. It's not a , and you never write it by hand anyway (all GraphQL clients can do introspection in one command), so let's look at the result of this query instead: it's the server . For my example Twitter API server, the GraphQL schema looks like this: __schema introspection particularly readable query schema # entry pointstype Query { Tweet(id: ID!): Tweet Tweets(limit: Int, sortField: String, sortOrder: String): [Tweet] TweetsMeta: Meta User: User Notifications(limit: Int): [Notification] NotificationsMeta: Meta}type Mutation { createTweet (body: String): Tweet deleteTweet(id: ID!): Tweet markTweetRead(id: ID!): Boolean}type Subscription { tweetPublished(userId: ID!): Tweet}# custom typestype Tweet { id: ID! # The tweet text. No more than 140 characters! body: String # When the tweet was published date: Date # Who published the tweet Author: User # Views, retweets, likes, etc Stats: Stat}type User { id: ID! username: String first_name: String last_name: String full_name: String name: String @deprecated avatar_url: Url}type Stat { views: Int likes: Int retweets: Int responses: Int}type Notification { id: ID date: Date type: String}type Meta { count: Int}# custom scalar typesscalar Urlscalar Date Whoa, this server exposes a lot of things! At a glance, I can tell by reading the schema that: I can data about tweets, users and notifications (the lists the read entry points) read type Query I can tweets, and mark one as read (the lists the write entry points) create and delete type Mutation I can to new tweets published for a given user (the lists the pub/sub entry points) subscribe type Subscription Each of these entry points have a return type, and the schema lists the available fields for all these types. So for instance, the query returns a list of records of the type, which exposes , , , , and fields. These fields are also typed, either with a scalar type ( , , or , which is like a ), or with a custom type ( and ), for which I can also see the available fields. Tweets Tweet id body date Author Stats Int String ID String User Stat A GraphQL schema is like the Swagger of REST APIs. It contains all you need to know to interact with the server. In practice, and unlike in this article, development in GraphQL is schema-first. Frontend and backend developers start by agreeing on a schema. They define the contract between the frontend and the backend. Then, each team develops their own part, without any surprise. You’ll see how that works in the next post in this series. : GraphQL recommends using the type for primary keys. That means that GraphQL expects record to be identified by a . This also explains why, in the GraphQL results above, the field has string values even though the values are numeric. Note ID string Tweet.id : You may have noticed the declaration. It's a type declaration that most schemas contain, because the GraphQL specification doesn't define a type by default! Note scalar Date Date GraphQL is a Declarative Query Language You probably noticed that the schema syntax looks a lot like the query syntax. That’s because it’s the same. This JSON-like, comma-free, no-semicolon language is called . It’s used to describe types, queries, mutations, fragments, subscriptions. There is , but you’ve already learned the basics: the graphql language an entire website dedicated to it GraphQL provides built-in scalar types for , , , , and . String Int Float Boolean ID You can define an Object type by starting a declaration. An Object type contains fields, one per line. Each field has a name and a type, which can be either an object type, or a scalar type type Object fields can have parameters (as in the query), inside parentheses. These parameters have types, too. Notifications Required fields have an exclamation point stuck to their type name (e.g. ) ID! You can add comments (starting with a sign) # The schema can contain annotations, called (as the name field) directives @deprecated You can define a Scalar type by starting a declaration scalar The schema doesn’t explain the server fetches the result, it describes the result should look like. In that sense, the graphql language is, just like SQL, a language. But unlike SQL, a GraphQL request and response are very much lookalike — you always know what to expect. how what declarative In practice, in order to write a GraphQL query, I first think about the result I’m expecting, for instance: { Tweets: [ { id: 752, body: "consectetur adipisicing elit", date: "2017-07-15T13:17:42.772Z", Author: { username: "alang", full_name: "Adrian Lang", avatar_url: "http://avatar.acme.com/02ac660cdda7a52556faf332e80de6d8" }, { id: 123, body: "Lorem Ipsum dolor sit amet", date: "2017-07-14T12:44:17.449Z", Author: { username: "creilly17", full_name: "Carole Reilly", avatar_url: "http://avatar.acme.com/5be5ce9aba93c62ea7dcdc8abdd0b26b" }, }, // etc. ], User: { full_name: "John Doe" }, NotificationsMeta: { count: 12 }} Then I remove the colons, commas, and the values. Finally, I add in the parameters. The result is the GraphQL query to get that result: { Tweets(limit: 10, sortField: "date", sortOrder: "DESC") { id body date Author { username full_name avatar_url } } User { full_name } NotificationsMeta { count }} With GraphQL, I’m sure of what the response contains, regardless of the technology used to implement the GraphQL server. I started appreciating this advantage after my first GraphQL project, when I understood that all I had learned on the first project was directly applicable to the second one. If you feel that repeating the list of fields you want in every query is cumbersome, check out GraphQL — they’re kind of like macros. Tip: fragments Mutations and Subscriptions I’ve already explained how to call a : Query { Tweet(id: 123) { id body date }} Actually, GraphQL expects the request to start with a keyword defining the type of entry point targeted by the request. In the absence of keyword, it falls back to , but I can also make it explicit: query query { Tweet(id: 123) { id body date }} And just like that, you’ve just learned how to call mutations and subscriptions: just prefix the request with the proper keyword: mutation { createTweet(body: "Hello, world!") { id body date }} subscription { tweetPublished(userId: 123) { id date body Author { username full_name avatar_url } }} A GraphQL query can only contain one of the three keywords , , and . That means you can't aggregate read and write operations in a single query. query mutation subscription : GraphQL doesn’t specify the transport to use for the realtime subscriptions. It’s usually WebSockets, but you can use iOS push notifications, long polling, or even email! Note It’s a good practice to your requests. You can add a name between the keyword and the opening bracket, like so: Tip: name query getTweetDetail { Tweet(id: 123) { id body date }} This will come in handy when debugging GraphQL on the client side, as debug tools list the queries made by the client by name. Variables And Prepared Queries In the first example, I’ve asked for the of id : Tweet 123 ----------------------------------- requestPOST / HTTP 1.1Host: http://graphql.acme.com/Content-Type: application/graphql{ Tweet(id: 123) { id body date }} To build such a query, I have to concatenate or interpolate a value ( ) into a string. This opens the path to injection attacks - not SQL injection, but GraphQL injection. 123 To make this query safe, I can transform the value into a variable, and tell GraphQL to bind the value to this variable. If this sounds like prepared statements in SQL, that's on purpose. 123 $id 123 To use a variable in a GraphQL query, I have to declare it at the top of the query, before the opening bracket, and specify its type. As for the variable value, I can pass it in the query string, as a serialized JSON object: ----------------------------------- requestPOST /?variables={"id":123} HTTP 1.1Host: http://graphql.acme.com/Content-Type: application/graphql($id: ID!) { Tweet(id: $id) { id body date }} Now the query is safe from injection attacks. In addition to allowing reusability of queries, graphql variables facilitate cumbersome String interpolation and escaping. If you’re looking for a way to remember the GraphQL syntax, I recommend . Tip: the GraphQL cheat sheet by Hafiz Ismail GraphQL Sits Between the Client and the Server At that point, developers often wonder: Okay, GraphQL is a language, but how does that translate into my software architecture? Basically, a GraphQL server is an API gateway, a proxy between clients and a backend server. The backend server can be anything (REST API, relational database, NoSQL database). You can even use several backends and hide them behind a single GraphQL (proxy) server. The GraphQL server comes in various languages, the first one being Node.js. But you’re not constrained to JavaScript if it doesn’t make sense for your team. You won’t have to write much code on the server anyway — you can even use a Backend-as-a-Service tool like the excellent to deal with the GraphQL server side for you. GraphCool There is also usually a small GraphQL SDK sitting on the client side, helping to build requests and decode responses. This is entirely optional, but that’s the advantage of using a : you don’t have to rewrite the code for every project. standard GraphQL In a Nutshell So GraphQL is a “query language”, just like HTTP verbs and resource URLs are the “query language” of REST. But this language is much more developed and standardized than REST. GraphQL is an API gateway, or a proxy server that sits in front of data backends. GraphQL is a DSL to express the business logic exposed to clients GraphQL is a declarative query language. Clients get what they ask for. GraphQL is designed for Remote Procedure Call, and not limited to CRUD. GraphQL is a strong, statically typed language. It makes development faster and less error-prone. GraphQL supports read, write, and subscribe operations GraphQL moves the center of gravity towards the client. The client decides what fields they get in the response, not the server. GraphQL works on HTTP… but not only. It’s a specification for fetching and updating data that can be implemented in any protocol GraphQL supports aggregations and combinations of multiple resources in a single request out of the box GraphQL servers offer built-in API documentation GraphQL supports API evolution, and allows for deprecation warnings GraphQL does not care about the backend storage. You can keep your database, you can even keep your REST API if it’s still used. All in all, , redesigned from the ground up with the most important lesson learned from REST: simplicity. And I believe it’s a great idea. GraphQL is not the next REST, it’s the next SOAP Okay, you’ve read enough about what GraphQL is. It’s time to develop with GraphQL, for real. In , I’ll teach you to develop a GraphQL server in Node.js for a Twitter-like mobile app. the next post of this series Originally published at marmelab.com on September 5, 2017.
