Building simple Point of Sale system with Node.js & React.js

Building real time applications can be exciting, the idea that pages can be updated without reloading has always been of interest to me.For the this tutorial we will be creating a real-time point of sale system using node.js and react.js and see here Get the source code demo This tutorial will comprise of three parts: Part 1 (BackEnd) Frameworks description Building the Node app from scratch Testing with Postman 1.Creating a Template React app.2.Creating Routes and Views with Code Description. Part 2 (FrontEnd) I recommend using the for this tutorial. Vscode Editor Frameworks Description and Installation Below are the libraries and frameworks we will be using: : NeDB is much like SQLite in that it is a smaller, embeddable version of a much larger database system.NeDB is a smaller NoSQL datastore that mimics MongoDB. nedb :Socket.IO enables real-time bidirectional event-based communication.It works on every platform, browser or device, focusing equally on reliability and speed. : Express is a Fast, unopinionated, minimalist web framework for Node.js. express features will enable us to create our web server. : Nodemon checks for changes in your source and automatically restart your server. : body-parser extract the entire body portion of an incoming request stream and exposes it on req.body . : Http allows Node.js to transfer data over the Hyper Text Transfer Protocol (HTTP). socket.io express async nodemon body-parser http Let’s continue by creating the backend with node.js, I will assume you have . node and npm installed ** Building the Node app from scratch** For this tutorial we are going to create the Node app (express app) from scratch. it can also be done automatically using the . ejs template Create a directory via your Command Line Interface (CLI) named real-time-pos-system mkdir real-rime-pos-system Access the folder via CLI thus: cd real-time-pos-system Inside your real-time-pos-system folder create new folder named server from CLI mkdir server Let’s install our dependencies: npm init Press enter button for the following asked questions: package name: (server) Press Enter version: (1.0.0) Press Enter description: Node.js app that connect the react-pos app to the Database entry point:(index.js) Press Enter test command: Press Enter git repository: Press Enter keywords: Press Enter author: Enter Your Name license: (ISC) MIT you will be shown the following message: { "name": "server" version: "1.0.0" "description": "Node.js app that connect the react-pos app to the Database "main" : "index.js", "scripts": { test": "echo \"Error: no test specified\ specified\" && exit 1" }, "author": "Your Name", "license": "MIT" }

Is this ok?(yes) yes : Install the following dependencies npm install express --save npm install http --save npm install nodemon --save npm install nedb --save Create a file named index.js in your real-time-pos-system folder using your Editor. index.js is the entry point for our node app, as you can see it is located in the root of our app. insert the following code in your index.js file var express = require("express"), http = require("http"), port = 80, app = require("express")(), server = http.createServer(app), bodyParser = require("body-parser"), io = require("socket.io")(server), liveCart;

console.log("Real time POS running"); console.log("Server started"); app.use(bodyParser.json()); app.use(bodyParser.urlencoded({ extended: false }));

app.all("/*", function(req, res, next) { // CORS headers res.header("Access-Control-Allow-Origin", "*"); // restrict it to the required domain res.header("Access-Control-Allow-Methods", "GET,PUT,POST,DELETE,OPTIONS"); // Set custom headers for CORS res.header( "Access-Control-Allow-Headers", "Content-type,Accept,X-Access-Token,X-Key" ); if (req.method == "OPTIONS") { res.status(200).end(); } else { next(); } });

app.get("/", function(req, res) { res.send(" Real time POS web app running."); });

app.use("/api/inventory", require("./api/inventory")); app.use("/api", require("./api/transactions"));

// Websocket logic for Live Cart io.on("connection", function(socket) { socket.on("cart-transaction-complete", function() { socket.broadcast.emit("update-live-cart-display", {}); });

// on page load, show user current cart socket.on("live-cart-page-loaded", function() { socket.emit("update-live-cart-display", liveCart); });

// when client connected, make client update live cart socket.emit("update-live-cart-display", liveCart);

// when the cart data is updated by the POS socket.on("update-live-cart", function(cartData) { // keep track of it liveCart = cartData;

// broadcast updated live cart to all websocket clients socket.broadcast.emit("update-live-cart-display", liveCart); }); });

server.listen(port, () => console.log(`Listening on port ${port}`)); index.js Explained This file is the entry point to our node express app. it is comprised of routes that will handle requests and responses to and from the browser. Below are dependencies assigned to variables. var express = require("express"), http = require("http"), port = 80, app = require("express")(), server = http.createServer(app), bodyParser = require("body-parser"), io = require("socket.io")(server), liveCart Below, The express variable app is used to allows data to be sent to the database using http request body. app.use(bodyParser.json()); app.use(bodyParser.urlencoded({ extended: false })) Below are imported files that will represent inventory and transaction routes. app.use("/api/inventory", require("./api/inventory")) app.use("/api/transactions", require("./api/transactions")) Cross-origin resource sharing (CORS) is a mechanism that allows restricted resources (e.g. fonts) on a web page to be requested from another domain outside the domain from which the first resource was served. — Wikipedia Below, the node app is restricted to resources within using CORS and allows specified methods GET PUT POST DELETE and OPTIONS to be used. app.all("/*", function(req, res, next) { // CORS headers res.header("Access-Control-Allow-Origin", "*"); // restrict it to the required domain res.header("Access-Control-Allow-Methods", "GET,PUT,POST,DELETE,OPTIONS"); // Set custom headers for CORS res.header( "Access-Control-Allow-Headers", "Content-type,Accept,X-Access-Token,X-Key" ); if (req.method == "OPTIONS") { res.status(200).end(); } else { next(); } }); Below is the Node app default route app.get("/", function(req, res) { res.send(" Real time POS web app running."); }); The Websocket logic for Live Cart io.on("connection", function(socket) { socket.on("cart-transaction-complete", function() { socket.broadcast.emit("update-live-cart-display", {}); }); On page load, give user current cart socket.on("live-cart-page-loaded", function() { socket.emit("update-live-cart-display", liveCart); }); On page load, make client update live cart socket.emit("update-live-cart-display", liveCart) When the cart data is updated by the POS and keeps track of it socket.on("update-live-cart", function(cartData) { liveCart = cartData; Broadcasts updated live cart to all websocket clients socket.broadcast.emit("update-live-cart-display", liveCart); }); Let’s continue, create a directory inside server directory: mkdir api Create two files named inventory.js and transactions.js in your api folder insert the following code to your inventory.js: var app = require("express")(); var server = require("http").Server(app); var bodyParser = require("body-parser"); var Datastore = require("nedb"); var async = require("async");

app.use(bodyParser.json());

module.exports = app;

// Creates Database var inventoryDB = new Datastore({ filename: "./server/databases/inventory.db", autoload: true });

// GET inventory app.get("/", function(req, res) { res.send("Inventory API"); });

// GET a product from inventory by _id app.get("/product/:productId", function(req, res) { if (!req.params.productId) { res.status(500).send("ID field is required."); } else { inventoryDB.findOne({ _id: req.params.productId }, function(err, product) { res.send(product); }); } });

// GET all inventory products app.get("/products", function(req, res) { inventoryDB.find({}, function(err, docs) { console.log("sending inventory products"); res.send(docs); }); });

// Create inventory product app.post("/product", function(req, res) { var newProduct = req.body;

inventoryDB.insert(newProduct, function(err, product) { if (err) res.status(500).send(err); else res.send(product); }); });

app.delete("/product/:productId", function(req, res) { inventoryDB.remove({ _id: req.params.productId }, function(err, numRemoved) { if (err) res.status(500).send(err); else res.sendStatus(200); }); });

// Updates inventory product app.put("/product", function(req, res) { var productId = req.body._id;

inventoryDB.update({ _id: productId }, req.body, {}, function( err, numReplaced, product ) { if (err) res.status(500).send(err); else res.sendStatus(200); }); });

app.decrementInventory = function(products) { async.eachSeries(products, function(transactionProduct, callback) { inventoryDB.findOne({ _id: transactionProduct._id }, function( err, product ) { // catch manually added items (don't exist in inventory) if (!product || !product.quantity_on_hand) { callback(); } else { var updatedQuantity = parseInt(product.quantity_on_hand) - parseInt(transactionProduct.quantity);

inventoryDB.update( { _id: product._id }, { $set: { quantity_on_hand: updatedQuantity } }, {}, callback ); } }); }); }; The necessary dependencies are assigned to variables app, server, bodyParser and Datastore. The app.use(bodyParser.json()) will allow the body of a http request to sent to the database. inventory.js Explained An inventory variable inventoryDB is assigned with an instance of variable Datastore we created earlier. The DataStoreinstance has two options filename which specifies the path of the database and autoload, which autumatically loads the database if set to true. nedb The app.get("/, function(req, res) function is the default path for the inventory database. The app.get("/product/:/productId function enables the app to get a product from the inventory database using it's ID. The app.get("/products", function(req, res) function gets all products from the inventory database. The app.post("/product", function(req, res) function is used to save an inventory product to the database. The app.delete("/product/:productId", function(req, res) is used to delete product using product ID. The app.put("/product", function(req, res) updates a product using it product ID. Let’s continue, insert the following code to your transaction.js file: var app = require('express')() var server = require('http').Server(app) var bodyParser = require('body-parser') var Datastore = require('nedb')

var Inventory = require('./inventory')

app.use(bodyParser.json())

module.exports = app

// Create Database var Transactions = new Datastore({ filename: './server/databases/transactions.db', autoload: true })

app.get('/', function (req, res) { res.send('Transactions API') })

// GET all transactions app.get('/all', function (req, res) {

Transactions.find({}, function (err, docs) { res.send(docs) }) })

// GET all transactions app.get('/limit', function (req, res) {

var limit = parseInt(req.query.limit, 10) if (!limit) limit = 5

Transactions.find({}).limit(limit).sort({ date: -1 }).exec(function (err, docs) { res.send(docs) }) })

// GET total sales for the current day app.get('/day-total', function (req, res) {

// if date is provided if (req.query.date) { startDate = new Date(req.query.date) startDate.setHours(0,0,0,0)

endDate = new Date(req.query.date) endDate.setHours(23,59,59,999) } else {

// beginning of current day var startDate = new Date() startDate.setHours(0,0,0,0)

// end of current day var endDate = new Date() endDate.setHours(23,59,59,999) }

Transactions.find({ date: { $gte: startDate.toJSON(), $lte: endDate.toJSON() } }, function (err, docs) { var result = { date: startDate }

if (docs) {

var total = docs.reduce(function (p, c) { return p + c.total }, 0.00)

result.total = parseFloat(parseFloat(total).toFixed(2))

res.send(result) } else { result.total = 0 res.send(result) } }) })

// GET transactions for a particular date app.get('/by-date', function (req, res) { var startDate = new Date(2018, 2, 21) startDate.setHours(0,0,0,0)

var endDate = new Date(2015, 2, 21) endDate.setHours(23,59,59,999)

Transactions.find({ date: { $gte: startDate.toJSON(), $lte: endDate.toJSON() } }, function (err, docs) { if (docs) res.send(docs) }) })

// Add new transaction app.post('/new', function (req, res) {

var newTransaction = req.body Transactions.insert(newTransaction, function (err, transaction) { if (err) res.status(500).send(err) else { res.sendStatus(200) Inventory.decrementInventory(transaction.products) } }) })

// GET a single transaction app.get('/:transactionId', function (req, res) {

Transactions.find({ _id: req.params.transactionId }, function (err, doc) { if (doc) res.send(doc[0]) }) }) The necessary dependencies are assigned to variables as was done previously. transaction.js Explained A Transaction’s variable is created with filename and autoload using the variable Datastore as done earlier. nedb The app.get("/, function(req, res) function is the default path for the transactions database. The app.get('/all', function (req, res) function retrieves all transactions from the transactions database. The app.get('/limit', function (req, res) function retrieves transactions with specified limit. The app.get('/day-total', function (req, res) function is gets total sales for the current day. The app.get('/by-date', function (req, res) function is used to get transactions using a particular date The app.post('/new', function (req, res)) function is used to add new a transaction The app.get('/:transactionId', function (req, res) function is used to retrieve a single transaction. : To Start Node app from root directory using CLI , type command nodemon index.js end in backend section Frontend part We are going to accomplish the following: 1.Creating a Template React app.2.Creating Routes and Views with Code Description. See for source codeFrameworks we will be using: here is a Promise based HTTP client for the browser and node.js. axios is a free open source library that contains HTML and CSS design templates for designing websites and web applications. Bootstrap is a Bootstrap 3 components built with React. React-Bootstrap is a lightweight JavaScript date library for parsing, validating, manipulating, and formatting dates. moment is a JavaScript library for building user interfaces. React Creating a Template React App Make sure you have installed. Node and NPM Check Node and Npm Version via Command Line Interface (CLI) node -v npm -v Access the real-time-pos-folder we used in part 1 Using CLI to create react app globally using npm: For npm version 5.1 or earliernpm install -g create-react-app To create your app, run a single commandnpm install create-react-app react-pos For npm version 5.2+ and highernpx install -g create-react-app To create our appointment scheduler app, run a single commandnpx install create-react-app react-pos The Directory of your app will look something like this: react-pos├── README.md├── node_modules├── package.json├── .gitignore├── public│ └── favicon.ico│ └── index.html│ └── manifest.json└── src└── App.css└── App.js└── App.test.js└── index.css└── index.js└── logo.svg└── registerServiceWorker.js To start the project in development mode via CLInpm start Access your app directory using:cd react-pos Install the following dependencies:npm install bootstrap npm install react-bootstrap npm install axios npm install moment Creating Routes and Views We are going to start by creating our routes Start by editing your App.js in your root directory with following code: import React from "react"; import Header from "./js/components/Header"; import Main from "./js/components/Main";

const App = () => ( );

export default App; Also update your index.js in your root directory: import React from "react"; import { render } from "react-dom"; import { BrowserRouter } from "react-router-dom"; import registerServiceWorker from "./registerServiceWorker"; import "./index.css"; import "bootstrap/dist/css/bootstrap.css"; import { makeRoutes } from "./routes"; import App from "./App";

render( , document.getElementById("root") ); registerServiceWorker(); You maybe wondering about the Main and Header Components, but we will create them shortly: Create the following path in your “src” folder directory of your react-pos app: js/components Create Main.js in the js/components folder with the following code: import React from "react"; import { Switch, Route } from "react-router-dom"; import Inventory from "./Inventory"; import Pos from "./Pos"; import Transactions from "./Transactions"; import LiveCart from "./LiveCart";

const Main = () => ( );

export default Main; Notice that our Main.js component is not a class; rather it is a functional component,. Arrow function to be precise. we are creating our routes using functions. Lets create our Header.js component for navigation of our app import React from "react"; import { Link } from "react-router-dom";

// The Header creates links that can be used to navigate // between routes. const Header = () => ( Real Time Point POS

Inventory POS Transactions LiveCart );

export default Header; you will notice as we continue that the Header component is included in all parent components. Now lets create our views, Let’s start with the Inventory.js component in the src/js/component/ folder. import React, { Component } from "react"; import "./App.css"; import Header from "./Header"; import Product from "./Product"; import axios from "axios";

const HOST = "http://localhost:80";

class Inventory extends Component { constructor(props) { super(props);

this.state = { products: [] }; } componentWillMount() { var url = HOST + `/api/inventory/products`; axios.get(url).then(response => { this.setState({ products: response.data }); }); } render() { var { products } = this.state;

var renderProducts = () => { if (products.length === 0) { return {products}

; } return products.map(product => ); };

return (

Add New Item

Name Price Quantity on Hand {renderProducts()} ); } }

export default Inventory; Notice that We are using a class for the inventory component above. componentWillMount is a Lifecycle method which is used to modify the component state, in this particular situation we are retrieving products from the inventory database by through our Node.js Express App We created in part 1. the response is assigned to the product array using setState . All this is done before the page is fully loaded. The render function will display our UI elements in the DOM (Document Object Model). The renderFunction checks the product array and display the result in the DOM. Let’s move on to the POS.js Component. The Pos component will allows the user to add items to cart with prices. the cart will be updated in real time. Create a Pos.js file in src/js/component/ folder: import React, { Component } from "react"; import "./App.css"; import Header from "./Header"; import io from "socket.io-client"; import axios from "axios"; import moment from "moment"; import { Modal, Button } from "react-bootstrap"; import LivePos from "./LivePos";

const HOST = "http://localhost:80"; let socket = io.connect(HOST);

class Pos extends Component { constructor(props) { super(props); this.state = { items: [], quantity: 1, id: 0, open: true, close: false, addItemModal: false, checkOutModal: false, amountDueModal: false, totalPayment: 0, total: 0, changeDue: 0, name: "", price: 0 }; this.handleSubmit = this.handleSubmit.bind(this); this.handleName = this.handleName.bind(this); this.handlePrice = this.handlePrice.bind(this); this.handlePayment = this.handlePayment.bind(this); this.handleQuantityChange = this.handleQuantityChange.bind(this); this.handleCheckOut = this.handleCheckOut.bind(this); } componentDidUpdate() { if (this.state.items.length !== 0) { socket.emit("update-live-cart", this.state.items); } } handleSubmit = e => { e.preventDefault(); this.setState({ addItemModal: false });

var renderAmountDue = () => { return ( Amount Amount Due: {this.state.changeDue} Customer payment incomplete; Correct and Try again

this.setState({ amountDueModal: false })}> close ); }; var renderReceipt = () => { return ( Receipt Total: {this.state.totalPayment} Change Due: {this.state.changeDue} this.setState({ receiptModal: false })}> close ); };

var renderLivePos = () => { if (items.length === 0) { return No products added

; } else { return items.map( item => ( ), this ); } };

return ( Total ${this.state.total}

C h e c k o u t Checkout Total: {this.state.total}

$ this.setState({ totalPayment: event.target.value }) } min="0" />

Enter payment amount.

Print Receipt this.setState({ checkOutModal: false })} > Close {renderAmountDue()} {renderReceipt()} this.setState({ addItemModal: true })} class="btn btn-default btn-sm" > Add Item Add item(Product) Name Price $

Enter price for item.

Add this.setState({ addItemModal: false })} > Cancel Name Price Quantity Tax Total {renderLivePos()} ); } }

export default Pos; The Pos component enables the user to add items to cart, accept payment via checkout, print the receipt and saves to the database. The componentDidUpdate Lifecycle method is used to check the state of the itemsarray everytime the component has been updated. if the item array contain one or more products the LiveCart is updated in real-time using socket.io. The handleSubmit function adds an item to the item array. The handlePrice function assigns the current price of an item to the price variable using the setState The handleName function assigns the current name of an item to the name variable using the setState The handlePayment function checks the amount the customer payment paid for the items against the total cost. The handleQuantityChange function is a prop of the child component LivePos, it updates the quantity of an item when the user increases or reduces it. The handleCheckout function calculates the total cost of items purchased by the customer and updates total using setState. The renderLivePos function renders an item as it is added to the item array using the child component LivePos. The renderReceipt displays a modal confirming payment. The renderAmountDue display a modal to inform the user of incomplete payment. The LivePos is a child component of the Pos component. it display each item as it added to the Pos component. The LivePos is also known as a Presentation component. check the source this component code The handleSaveToDB function saves the transaction to the database Let’s proceed to the Livecart component: import React, { Component } from "react"; import "./App.css"; import io from "socket.io-client"; import Header from "./Header"; import axios from "axios"; import RecentTransactions from "./RecentTransactions"; import LiveTransactions from "./LiveTransactions"; import moment from "moment";

var socket = io.connect(HOST);

socket.on("update-live-cart-display", liveCart => { this.setState({ liveTransactions: liveCart }); }); } componentWillUnmount() { // socket.disconnect(); // alert("Disconnecting Socket as component will unmount"); } render() { var { transactions, liveTransactions } = this.state; var renderRecentTransactions = () => { if (transactions.length === 0) { return No recent transactions available

; } else { return transactions.map(transaction => ( )); } }; var renderDate = () => { return moment().format("DD-MMM-YYYY HH:mm:ss"); }; var renderLiveTransactions = () => { if (liveTransactions.length === 0) { return ( Not Active: No items added at the moment. ); } else { return liveTransactions.map(liveTransaction => ( )); } }; return ( {renderDate()}

Quantity Product Price {renderLiveTransactions()} Recent Transactions

Today's Sales $

Time Total {renderRecentTransactions()} ); } }

export default LiveCart; The LiveCart component renders recent and current transactions. On ComponentWillMount recent transactions are retrieved, followed by current items on livecart using socket.io-client render function display the user interface to DOM. renderRecentTransactions childcomponent is used to render recent transactions saved to the Database. renderLiveTransactions is also a child component used to render current transactions. Both renderRecentTransactions and renderLiveTransactions are presentational components. Let’s move on to the Transaction component: import React, { Component } from "react"; import "./App.css"; import Header from "./Header"; import CompleteTransactions from "./CompleteTransactions"; import axios from "axios";

const HOST = "http://localhost:80"; const url = HOST + `/api/all`;

class Transactions extends Component { constructor(props) { super(props); this.state = { transactions: [] }; } componentWillMount() { axios.get(url).then(response => { this.setState({ transactions: response.data }); console.log("response:", response.data); }); } render() { var { transactions } = this.state;

var rendertransactions = () => { if (transactions.length === 0) { return No Transactions found

; } return transactions.map(transaction => ( )); };

return ( Today's Sales $

Time Total Products Open {rendertransactions()} ); } }

export default Transactions; On the componentWillMount all transactions and retrieved from the database. The rendertransactions function displays all the transactions using the CompleteTransactions presentional component. See source code for more on 'CompleteTransactions. We have succeeded in building The front and Backend of Real time Point of Sale System. I hope you had a blast. ✉️ CodeBurst’s 🐦 CodeBurst 🗺️ 🕸️ Subscribe to once-weekly Email Blast , Follow on Twitter , view The 2018 Web Developer Roadmap , and Learn Full Stack Web Development .
